Single axle trailer
5T sigle axle trailer

名称:5T sigle axle trailer

详细信息

Model

7CX-5

(mm)
     Carriage dimension Length*width*height

3700*1900*(460+460)

(mm)
     Overall dimensions Length*width*height

5020*1990*1855

(kg)
     Rated weight

5000

(kg)
     Dead weight

1350


     Specification of tire/qty

400/60*15.5 14PR/2

Brake

hydraulic/air brake


     Tipping pattern

rear tip

(HP)
     Matched power

40-50

    我公司设计、生产7C系列液压自卸拖车,可实现左右倾翻、向后自翻的卸载方式。欧式无减震,自卸拖车系我公司产品,该拖车在卸货的过程中,能向后左右方倾翻,方便了由于场地狭小带来的不便。适用于运输重载货物,和长短途运输,该车配置齐全、行驶平稳、外型美观、经久耐用,作业环境广泛,装载效率高。

7C series hydraulic dump trailer, can realize left and right tilting, backward self - flipping unloading mode.  No shock absorption, self-unloading trailer is my company's patented products, the trailer in the unloading process, can back to the left and right side of the tilt, great convenience due to the small space brought by the inconvenience.

Suitable for the transport of heavy cargo, and long and short distance transport, the car is fully equipped, smooth running, beautiful appearance, durable, extensive operating environment, high loading efficiency.
